Industrial curing oven
There is a wide range of curing applications found in a number of industries. A batch oven or conveyor oven can be used for the curing process based on the customer’s production requirements. Curing applications use heat to create a chemical reaction to cure a finish or adhesive onto a product, or to solidify a plastic or epoxy. The result is a harder, tougher, more stable material or coating that resists temperature, humidity, and/or corrosion. These curing ovens provide excellent temperature uniformity, so your parts receive the optimal cure.
With a Curing Oven from GBM Oven, you will be able to meet tight temperature tolerances and consistent results while remaining cost-effective. GBM Oven batch and conveyorized Curing Ovens are available as either electric or gas heated and have multiple customization options.
Options
- Exhaust Blower
- Vertical Door
- Front & Back Door
- PLC with HMI
- Forced Exhaust
- Observation Window & Illumination
- Spare Parts
- Blower Burner Interlock
- PID Controller with SSR/SCR
- Thyristor
Specifications
| Design | Batch Type/ Modular/ Cassette Type |
| Outer Chamber Construction | HR/CR. |
| Inner Chamber Construction | MS Sheet, SS Sheet, or GI Sheets. |
| Insulation | Rock wool/ Mineral wool |
| Temperature Ranges | Ambient to 150°C /250°C /400°C/ 500°C |
| Air Circulation | Vertical, Horizontal or Combination |
| Paint | Enamel Paint / Epoxy Coating / Powder Coating |
| Temperature Uniformity | ± 5°C. |
| Control Panel | GBM Make. |
| Heating Element | SS Tubular Electrical Heaters / Imported Diesel Fired Burner / Imported Gas Fired Burner |
| Inner Finish | High Temperature Aluminium Finish |
| Outer Finish | Double Coat Enamel Finish |
| Trolley with Track | Yes |
